How do I assemble the handles on my Electric Lawnmower

Quick Answer

To assemble the handles on your electric lawnmower, fit the lower handles into the mower body, then attach the upper handle using the quick-release clamps. Ensure the bolts, washers and locking levers are fitted in the correct order before tightening.

Tip: Handle assembly varies slightly between models, but the quick-release clamps are assembled in the same way on most electric lawnmowers.

Before You Start

Before assembling the handles:

• Ensure the lawnmower is switched off
• Disconnect the mower from the mains power supply
• Lay the mower on a flat, stable surface
• Check that all supplied fixings are present

Important: Do not connect the mower to the power supply until assembly is complete.

How to Assemble the Lower Handles

Some models have lower handles that slot directly into the mower body.

1. Insert the lower handles

• Slide each lower handle fully into its mounting point
• Ensure both sides are inserted to the same depth

Some force may be required to fully seat the handles.

2. Secure the handles

Using the supplied screws:

• Align the fixing holes
• Tighten the screws securely

Check that the lower handles do not move once installed.

How to Assemble the Quick-Release Handle Clamps

The upper and lower handles are connected using quick-release clamps.

1. Insert the bolt

Insert the bolt through the handle from the inside of the frame.

The bolt head should sit on the inside of the handle.

2. Fit the washer

Place the washer over the threaded end of the bolt on the outside of the handle.

Ensure the washer sits flat against the handle frame.

3. Attach the quick-release lever

Thread the quick-release clamp onto the bolt.

Tighten until the handle is secure.

Push the quick-release lever down to lock the handle firmly into position.

Repeat the process on the opposite side.

Check the Handle Assembly

Before using the lawnmower:

• Ensure both quick-release levers are fully locked
• Check all screws are tightened securely
• Confirm the handles are stable and do not move during use

If You Are Still Having Problems

If:

• The bolt does not appear to be long enough
• The handles do not align correctly
• The quick-release clamps cannot be tightened
• The handles remain loose after assembly

Please contact our Technical Support Team for further assistance.

Important Assembly Tips

• Assemble all components before fully tightening the fixings.
• Ensure bolts, washers and quick-release levers are fitted in the correct order.
• Do not overtighten the quick-release clamps.
• Check all handle fixings before each use.

Frequently Asked Questions

How should the quick-release clamp be assembled?

Insert the bolt from the inside of the handle, fit the washer on the outside, thread the quick-release lever onto the bolt, tighten it, then push the lever down to lock it.

Why doesn't the bolt seem long enough?

This is usually caused by the components not being assembled in the correct order or the handle sections not being fully aligned.

Do the lower handles push into the mower?

Yes. On many models, the lower handles slot into the mower body before being secured with the supplied screws.

How do I know the handles are secure?

The handles should not move once all screws and quick-release clamps have been tightened and locked.

What should I do if I still can't assemble the handles?

If you have followed these instructions and the handles still do not fit correctly, please contact our Technical Support Team for further assistance.
